SCB Series Monorail Spinner Hanger Shot Blasting Machine

Release date：2021-12-02 　Number of hits：1

SCB Series Monorail Spinner Hanger Shot Blasting Machine

Product info:
● High efficiency & uniform cleaning effect
There is a no pit design, special hook design and operating by rotary drive system, especialy suit for decanding of complex castings and oxied layer removal of weldments. Have an excellent perfpormance.

● Heigh performance Shot、 Sand sepearator system

Specially designed separator can make foundry sand、 dust、 impurities completely separated with the abrasives improve service life of the consumables.

● Extremely long life of wear-resistant liners
The liner insinde the blast room used special material wear-resistant plates. Effectively proven wear and tear caused by abrasives.

● Additional unique components

Two direction work turbines and direction settings. Automaticlly open and close system etc. Additional features there are a variety of work piece walking layout potions

Model		SCB-10	SCB-25	SCB-25A	SCB-50
Treating Capacity	Workpiece Size h（mm）	1500	2000	2500	3000
	Workpiece Size φ（mm）	φ1200	φ1500	φ2000	φ2500
	Max. Hanger Load（t）	1	2.5	2.5	5
Blast wheel	Quantity	2	3	4	5
Blast wheel	Motor Power（kw）	7.51 111	7.52 111	7.53 111	7.54 111
Dust Collector	Required Air Ventalation（m3/min）	50	75	100	150
Dust Collector	Static Press（kPa）	2.5	2.5	2.5	2.5
Dimension of Machine	A（mm）	1800	2100	2850	3300
	B（mm）	1850	2100	2400	3100
	C（mm）	4300	5460	5950	7150
	D（mm）	4500	5700	6400	7600
	E（mm）	3010	3500	4020	4870
	F（mm）	5425	5875	7000	8950
