XQ Series Shot Blasting Machine For Wire

发布日期:2021-12-02    浏览次数:0

XQ Series Shot Blasting Machine For Wire

XQ Series Shot Blasting Machine For Wire

Product info:
Feature:
● Fine Total -protected none-pit design

● Equip with wire-specialized powerful built-in shotblast Tuebine

●The Vanes of shot blast were desjgned based on different wire size

●Consuamble parts are easy and quick replacement

●Surface is bright-silvery after cleaned

●They are easy to integrate into modern drawing lines operating at speeds of up to 120m/min




Technical Data
No    Model    XQ-Ⅱ
1    Diameter of Wire    mm    Φ5.5~40
2    Passage Speed    m/min    Max 120
3    Center Height    mm    1125
4    Impeller Motor Power    kW    15-22
5    Impeller Quantity
    4
6    Machine Length    mm    3600
7    Machine Width    mm        1575
8    Machine Height    mm    2650
9    Required Air Ventilation    m3/h    3000
